Description:
The VICTRON MultiPlus 24/1600/40 is a powerful and reliable inverter-charger combo, designed for the electrical installations of Motorhomes, camper vans, and boats. It combines a 24 V – 40 A battery charger and a 230 V – 1600 VA (1300 W continuous) inverter, to ensure stable and secure power supply.

Thanks to its automatic transfer switch, the system instantly switches to the external source (mains, generator, shore power), ensuring uninterrupted power continuity, ideal for sensitive equipment.

The MultiPlus features a Search mode that reduces no-load consumption (only 3 W), a programmable relay, and a VE.Bus port for network use with other VICTRON devices.

Robust and efficient, it guarantees high efficiency and includes several safety protections (overheating, short circuit, reverse polarity).

Key features:

• 24V/230V inverter: 1600 VA (1300 W continuous, 2800 W peak)

• Built-in 24 V – 40 A charger

• Automatic transfer switch mains/generator/inverter

• Search mode: reduced consumption (3 W)

• VE.Bus port for networking

• Robust casing, integrated ventilation

Technical specifications:

• Input voltage: 19 – 33 V

• Output: 230 V / 50-60 Hz

• High efficiency, low no-load consumption (9 W)

• Operating temperature: -40 °C to +65 °C

• Protection rating: IP21

• Battery connection: screw terminal (max cable 35 mm²)

• Dimensions: 470 x 265 x 120 mm

• Weight: 8.2 kg
