Description:
The VICTRON MultiPlus Compact 12/800/35 is a reliable and high-performance charger-inverter combo, specially designed for onboard installations in Motorhome, campervan, or boat.

This 12V device combines a 35A charger for your auxiliary batteries and a 230V 800VA inverter (700W continuous, 1600W peak). Once installed, it automatically switches between external power (mains socket, generator, etc.) and the inverter. Switching occurs in less than 20 milliseconds, ideal for protecting your sensitive devices.

The MultiPlus Compact also features a "Search" mode that reduces no-load consumption to only 3W, as well as a programmable relay to cut off the inverter in case of low voltage. Multiple units can be installed in parallel to create a three-phase system.

Main features:

• Built-in 12V 35A charger

• 230V inverter: 800VA / 700W continuous – 1600W peak

• Fast automatic switching (less than 20 ms)

• No-load consumption: 10W – Search mode: 3W

• VE.Bus port for networking with other VICTRON devices

• Operating temperature: -40 °C to +65 °C

• Protection rating: IP21

• Dimensions: 375 x 214 x 110 mm – Weight: 10 kg

• Optional ON/OFF remote control – temperature sensor included

A compact and robust combination unit, ideal for ensuring stable and secure power supply in all your onboard electrical installations.
