Description:
The build quality of VICTRON ENERGY products is recognized worldwide. Specialized in onboard energy systems, the company offers a range of MultiPlus Compact charger/inverter combos, perfectly suited for electrical installations in a camper van, motorhome, or boat.
The VICTRON MultiPlus Compact combines a 12V 70A charger for your auxiliary batteries and a powerful voltage inverter to power your 230V network. Once installed, the system automatically switches between external power (mains socket, generator, etc.) and the inverter. The charger starts as soon as an external source is available, and the switching occurs in less than 20 milliseconds, thus protecting your sensitive equipment.
With an output power of 1600VA (1300W continuous) and 2800W peak, this model ensures stable and efficient power supply. The programmable relay allows the inverter to be stopped in case of too low battery voltage. For larger installations, multiple inverters can be connected in parallel to obtain three-phase current.
The "Search" mode reduces no-load consumption by activating the inverter only when necessary.
Key features of the VICTRON ENERGY MultiPlus Compact:
-
Output power: 1300 W continuous / 2800 W peak
-
Automatic switching of the 230V source
-
Low no-load consumption: 8 W (Search mode: 8 W)
-
VE.Bus port for networking with other VICTRON devices
Technical specifications:
-
Output power: 1600 VA / 1300 W
-
Peak power: 2800 W
-
Output voltage and frequency: 230 V / 50-60 Hz
-
Input voltage: 9.5 – 17 V
-
Charger current: 70 A
-
No-load consumption: 8 W
-
Consumption in Search mode: 8 W
-
Operating temperature: -40 °C to +65 °C
-
Max humidity: 95 %
-
Cooling: built-in fan
-
Protection rating: IP21
-
Weight: 10 kg
-
Dimensions (H x W x D): 375 x 214 x 110 mm
-
ON/OFF remote control: optional
-
Robust metal chassis covered with plastic
-
Temperature sensor included
The VICTRON ENERGY MultiPlus Compact 12/1600/70 is the ideal solution for reliable and efficient management of your onboard electrical installation, ensuring stable and continuous power supply under all circumstances.
