Description:
The VICTRON Orion-Tr Smart 12/12-30A is a DC/DC booster charger designed to efficiently recharge your 12V auxiliary batteries from the starter battery and alternator. Ideal for campervans, Motorhomes, and boats, it ensures reliable and fast charging.

Compatible with AGM, GEL, and Lithium batteries, it uses a 3-stage charging algorithm (Bulk, Absorption, Float) to extend battery life. Thanks to its automatic engine running detection, it activates only when necessary, thus protecting your electrical system.

The built-in Bluetooth allows monitoring and configuring the charge via the VictronConnect app. Multiple chargers can be installed in parallel to increase power, and the Power Supply mode allows it to be used as a continuous power source.

Main features:

• Input voltage: 8 – 17 V

• Nominal output: 12.2 V (adjustable 10 – 15 V)

• Output current: 30 A (40 A max peak)

• Output power: 430 W (at 25 °C) / 360 W (at 40 °C)

• Efficiency: 87%

• 3-stage charging algorithm

• Built-in Bluetooth (VictronConnect)

• Protections: short circuit, overheating, reverse polarity

• Protection rating: IP43 (electronics) / IP22 (connections)

• Dimensions: 130 x 186 x 70 mm – Weight: 1.8 kg

An intelligent, robust, and versatile booster charger, perfect for ensuring the energy autonomy of your onboard installations.
