Product Description

The VICTRON MultiPlus 12/1200/50 is a combined intelligent inverter/charger, specially designed for the electrical installations of Motorhomes, camper vans, boats, or remote sites.

This versatile device combines a 50A battery charger for your auxiliary batteries (up to 500 Ah) and a 12V/230V inverter capable of delivering 1000 W continuous and 2400 W peak. It allows you to power your household appliances while ensuring reliable charging of your batteries.

Thanks to its ultra-fast automatic transfer switch (less than 20 ms), the MultiPlus switches seamlessly between power sources (shore power, generator, public grid, or batteries), ensuring continuity for sensitive equipment such as computers.

The Search mode reduces no-load consumption (3 W) when the inverter is not in use, improving energy efficiency. Additionally, its VE.Bus port allows networking with other VICTRON devices for scalable and high-performance installations.

Robust and secure, the MultiPlus is equipped with built-in protections against undervoltage, overheating, and features a programmable relay to protect your batteries.

Key Features:

• 2-in-1 inverter/charger: 12V → 230V

• Output power: 1000 W continuous / 2400 W peak

• Built-in battery charger: 50 A

• Automatic transfer switch between 230 V sources

• Low no-load consumption: 10 W (3 W in Search mode)

• VE.Bus port for networking and system expansion

Technical Specifications:

• Rated power: 1200 VA / 1000 W

• Peak power: 2400 W

• Input: 12 V (9.5 – 17 V)

• Output: 230 V – 50/60 Hz

• Charger current: 50 A

• No-load consumption: 10 W (3 W in Search mode)

• Operating temperature: -40 °C to +65 °C

• Max humidity: 95 %

• Cooling: built-in fan

• Protection rating: IP21

• Dimensions: 406 x 250 x 100 mm

• Weight: 8.2 kg

👉 The VICTRON MultiPlus 12/1200/50 is the ideal solution to combine power, reliability, and intelligent energy management in your converted vehicles or marine installations.
